Amarr 2743 Polyurethane Insulated
Overview
High R-Value Doors to Meet All Your Needs
At 3″ thick, the Polyurethane Insulated Amarr 2743 delivers maximum R-Value for buildings where premium energy efficiency and performance are requirements. This Super-Duty top-of-the-line high R-value door is constructed using 27-gauge exterior steel and foamed-in-place polyurethane insulation with a superior energy-efficient R-value of 28. It comes with a 10-year warranty and has a max standard. width f 40′ 2″ and a max standard. height of 26′ 1″.
- Rapid Install Artificial Lift: Designed specifically for commercial warehouse and dock doors and saves approximately 20 minutes of installation time per door due to fewer jamb attachments and a pre-assembled, one-piece track. Available for door sizes up to 9’4″x10′
- Track:All Amarr doors are available with both 2″ or 3″ track in Standard Lift, High Lift, Vertical Lift, Rapid Install Vertical Lift, Low Headroom, and Follow the Roof Pitch
- Springs: Torsion springs are oil tempered, helical wound, and custom computed for each door for a minimum 10,000 cycle life. Optional springs are available for up to 100,000 cycles.
-
Hardware: Galvanized steel hinges and track brackets. All rollers have a minimum of 10-ball bearings.
- Maximum Door Size: 40′ 2″ W x 26′ 1″ H
- Steel Thickness: 27 ga
Available with Rapid Install
The Rapid Install system for Amarr’s Vertical Lift doors is designed specifically for commercial sectional doors, saving approximately 20 minutes of installation time per door.
Simplified Track & Hardware
- Heavy .063 gauge 1-piece 2″ and 3″ vertical track
- Preassembled end-bearing plate
- Self-lubricating nylon rollers
- Widebody hinges
- Optional keyed hollow shaft
Reduced Installation Time
- Engineered for one-man installation
- Fewer trips up the wall
- Fewer components to assemble
- 10 fewer wall attachments
True White
Sandstone
Commercial Gray
Brown
24″ x 12″ insulated
24″ x 8″ insulated
| R-Value | 28.0 |
| Steel Thickness | 27 ga |
| Panel Design | Pencil Groove |
| Steel Embossment | Stucco |
| Construction Layers | Three |
| Max Std Width | 40’2″ |
| Max Std Height | 26’1″ |
| Door Thickness | 3″ (7.6cm) |
| U-Value | 0.036 |
Steel + Insulation + Steel
- Steel Exterior
- Polyurethane Insulation
- Steel Interior
- Interior Hinge Reinforcement
- Bottom Weather Seal
- R-Value*: 28.0
- 3” thick
- 27-gauge steel front
- 27-gauge steel interior panel
- 20-gauge continuous strip hinge reinforcement
- Available with Rapid Install
- 10-Year Limited Warranty
